Our Capabilities

DMG MORI 5-Axis CNC Mill (DMU 75)

X axis travel 29.5″ (749 mm)
Y axis travel 25.6″ (650 mm)
Z axis travel 22″ (559 mm)
Table diameter 25.6″ (650 mm)
Table Load 1323 lbs. (600 kg)

Doosan Mill (DNM 750 II)

X axis travel 80″ (1630 mm)
Y axis travel 30″ (762 mm)
Z axis travel 25.6″ (650 mm)
Table size 64.2″ x 29.9″ (1630 mm x 760 mm)
Table Load 3306 lbs. (1500 kg)

Milltronics Mill (VM25)

X axis travel 60″ (1270 mm)
Y axis travel 25″ (635 mm)
Z axis travel 24″ (610 mm)
Table size 56″ x 24″ (1420 mm x 610 mm)
Table Load 3500 lbs. (1580 kg)

Milltronics Mill (VM20ILXT)

X axis travel 40″ (1016 mm)
Y axis travel 20″ (508 mm)
Z axis travel 26″ (660 mm)
Table size 34″ x 20″ (864 mm x 508 mm)
Table Load 2000 lbs. (910 kg)

Okuma Mill (MC-V4020)

X axis travel 40″ (1016 mm)
Y axis travel 20.1″ (511 mm)
Z axis travel 17.7″ (450 mm)
Table size 48″ x 20″ (1219 mm x 508 mm)
Table Load 1500 lbs. (680 kg)

Epilog Laser Fusion Pro

Max Engraving Area: 48” x 36” (1219mm x 914mm)
Fiber and CO2
Max Material Thickness: 11.25” (286mm) (3” lens)

Doosan Lathe (Puma 2100SY)

Main Spindle Std Chuck: 8” (203 mm)
Swing Over Bed: 30.7” (780 mm)
Max Turn Length: 20.47” (520 mm)
Max Turn Diameter: 15.98” (406 mm)
Bar Capacity: 2.6” (66 mm)

Okuma Lathe (CAPTAIN L470)

Swing: 16.5″ (419 mm)
Swing Over Bed: 24.4″ (620 mm)
Distance Between Centers: 50″ (1270 mm)
Max Length: 49.2″ (1250 mm)
Max Bar: 3.62” (92 mm)

Wire EDM (Makino U6)

X axis travel 25.6″ (650 mm)
Y axis travel 17.7″ (450 mm)
Z axis travel 16.5″ (420 mm)
Table size 35.8” x 27.95″ (910 mm x 710 mm)
Tank Size 42.13” x 34.65″ (1070 mm x 880 mm)

Wire EDM (Makino Duo 43)

X axis travel 17.7″ (450 mm)
Y axis travel 12″ (305 mm)
Z axis travel 12.6″ (320 mm)
Table size 27.9″ x 22″ (709 mm x 559 mm)
Tank Size 35.25” x 29.72” (895 mm x 755 mm)

SHARP 2280B Precision Lathe

Swing Over Bed: 22″ (559 mm)
Swing Over Cross Slide: 13.2″ (335 mm)
Distance Between Centers: 80″ (2032 mm)
Bed Width: 15.75” (400 mm)

Bridgeport Mill (Series II)

X-Axis travel: 36” (914 mm)
Y-Axis travel: 12” (305 mm)
Z-Axis travel: 16” (406 mm)
Quill travel: 5” (127mm)
Ram travel: 12” (305 mm)

Welding

  • MIG and TIG welding, welds most Aluminums/Steels/Titanium, Plasma cutting (Hypertherm Powermax 600)
  • Welding Machines:
    • Millermatic 252 MIG Welder
    • Syncrowave 350 LX TIG Welder
    • Dynasty 200 DX TIG Welder
  • Welder Certifications:
    • AWS D1.2/D1.2M – Structural Welding Code – Aluminum
    • ANSI/AWS D1.1 – Structural Welding Code – Steel
    • AWS D17.1 – Specifications for Fusion Welding for Aerospace Applications
